0063020 : Watts 1" Reduced Pressure Zone Backflow Preventor, Bronze, 009-QT

$745.55

Qty:

Compare at:   $ 820.11
You Save:   $ 74.56

SKU:   0063020

    SHIPS: IMMEDIATELY

Watts 0063020 (009QT) 1" Reduced Pressure Zone Assemblies Backflow Preventer.
Series 009 Reduced Pressure Zone Assemblies prevent the reverse flow of polluted water from entering into the potable water supply due to backsiphonage and or backpressure. It consists of bronze body construction (1/4 to 2 in., 8 to 50mm) or FDA approved epoxy coated cast iron (2 1/2 to 3 in., 65 to 80mm), two, in-line independent check valves, replaceable check seats with an intermediate relief valve, and ball valve test cocks. Series 009 is ideal for protection of health hazard cross-connections or for containment at the service line entrance. Check with local water authorities for installation requirements. Maximum Working Pressure: 175psi (12.06 bar).

Single access cover and modular check construction for ease of maintenance
Top entry - all internals immediately accessible
Captured springs for safe maintenance
Internal relief valve for reduced installation clearances
Replaceable seats for economical repair
Bronze body construction for durability 1⁄4" – 2" (8 – 50mm)
Fused epoxy coated cast iron body 21⁄2" and 3" (65 and 80mm)
Ball valve test cocks — screwdriver slotted 1⁄4" – 2" (8 – 50mm)
Large body passages provides low pressure drop
Compact, space saving design
No special tools required for servicing
