25-90341 : DPDT HVAC Switching Semi-Enclosed Relay, 120V
Compare at: $ 64.10
You Save: $ 5.83
SHIPS: IMMEDIATELY
Semi-Enclosed Relay - 2 Pole HVAC Switching Relay.
Applications: Air Conditioning, Refrigeration, Heating and General Purpose Switching.
Semi-enclosed compact design
Quiet & reliable operations
Universal mounting bracket
Molded terminal numbers and circuit diagram on top of relay
UL & cUR (file E44211)
Replaces Honeywell, White-Rodgers/RBM & Mars (cross reference in packaging)
Dimensions 2.13" × 1.88" × 2.25".
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Type: | Semi-Enclosed Heavy Duty |
| Switching Type: | DPDT |
| Coil Volts: | 120 |
| Coil Frequency: | 50/60 Hz |
| Coil Insulation: | Class B |
| Coil Duty Cycle: | Continuous |
| Amps: | 16 |
| Amperage: | 16 |
| Full Load Amps @: | 13.8 |
| Full Loaded Amps: | 13.8 |
| Locked Rotor Amps: | 82.8 |
| HP: | 3/4 |
| Temperature Range: | -40°C (-40°F) to 54°C (130°F) |
| Temperature Range (F): | -40°C (-40°F) to 54°C (130°F) |
| Contact Material: | Silver Cadmium Oxide |
| Terminals: | 1/4" Quick-Connects |
| Weight: | 170.1 g (6 oz.) (Approx) |
| Has 360 Photos: | Yes |
Replaces Old Numbers: 777980014838, 90341, 90-341, P283-0341, W604300
