DR20-W : Leviton Decora Plus Receptacle, 20A, 125V, White

$9.99

Qty:

Compare at:   $ 10.99
You Save:   $ 1.00

SKU:   DR20-W

    SHIPS: IMMEDIATELY

Leviton 20 Amp, 125 Volt, NEMA 5-20R, 2P, 3W, Decora Plus Duplex Receptacle, Straight Blade, Commercial Grade, Self Grounding, Back & Side Wired, Steel Strap, - White

Grounding: Self-Grounding
Amperage: 20 Amp
Voltage: 125 Volt
NEMA: 5-20R
Pole: 2
Wire: 3
Color: White
At Rated Voltage: 1 HP
Dielectric Voltage: Withstands 2000V per UL498
Current Limiting: Full Rated Current
Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
Flammability: Rated V-2 per UL94
Operating Temperature: -40C to 60C
Face Material: Thermoplastic Nylon
Body Material: Thermoplastic Nylon
Line Contacts: Brass Triple-Wipe .031 Thick
Terminal Screws: Brass 10-32
Grounding Screw: Brass 8-32
Strap Material: Zinc-Plated Steel
Clamp Nuts: Zinc-Plated Steel
Ground Clips: Brass-Plated
Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
Terminal Accom.: 14-10 AWG
Product ID: Ratings are permanently marked on device
Termination: Back & Side
NEMA: WD-6
ANSI: C-73
UL498: File E13399
CSA C22.2 No. 42: File LR-406
NOM: 057
Warranty: 10 Year Limited
