R3-R322 : Exhaust Fan & Blower Motor, 3.3" Dia 1/60HP 1550RPM 115V, Broan
Compare at: $ 167.82
You Save: $ 15.26
SHIPS: IMMEDIATELY
Exhaust Fan Motor.
Works on these Fan Models 676, 684N, 712,721,722. and others that Require these specifications.
Replaces 30080111, 30080112
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Body Diameter (Inches): | 3.3 |
| Frame: | 3.3 |
| HP: | 1/60 |
| Volts: | 115 |
| Amps: | 0.80 |
| RPM: | 1550 |
| Speeds: | 1 |
| Rotation: Opposite Shaft End: | CW |
| Bearing: | Sleeve |
| Enclosure: | Open |
| Shaft: Diameter x Length (Inches): | 1/4 x 1.3 |
| Motor Type: | Shaded Pole |
| Body Length (Inches): | 2.0 |
| Mounting: | Stud |
| Wiring: | Cord W/ 2 Prong Plug |
| Volts (V): | 115 |
| Amperage: | 0.80 |
| Shaft Dimensions (in): | 1/4 x 1.3 |
| Mounting Type: | Stud |
| Has 360 Photos: | Yes |
Replaces Old Numbers: 184749, 23-GOPG-KF7G, 2868-405-121, 2868-405-196, 2868-405-220, 2868-405-233, 30080008, 30080012, 30080111, 30080112, 777980023281, B01MR6Q7MB, B01MUF6X48, JA2C489D, R322
