R3-R358 : Rotom 1/20HP Refrigeration Evaporator Coil Motor, 3.3" Dia. 1550RPM, 115V, Blanchard Ness, Bohn
Compare at: $ 101.34
You Save: $ 9.21
Rotom R3-R358 OEM Evaporator Coil Motor.
Applications Evaporator Coils, Coolers, Refrigeration Cases, Etc.
Use with Blanchard, Bohn and other Units needing these specifications.
Replaces E01007, E01057, E01058, 5001L, 8S, 4L
Product Specifications | |
---|---|
Body Diameter (Inches): | 3.3 |
Frame: | 3.3 |
HP: | 1/20 |
Volts: | 115 |
Amps: | 2.0 |
RPM: | 1,550 |
Speeds: | 1 |
Rotation: Opposite Shaft End: | CCW |
Bearing: | Sleeve |
Enclosure: | Open |
Shaft: Diameter x Length (Inches): | 5/16 x 3.2 |
Motor Type: | Shaded Pole |
Body Length (Inches): | 3.30 |
Mounting: | Stud |
Wiring: | Leed with 2 Pin Plug |
Frequency: | 60Hz |
Phase: | 1 |
Thermal Protection: | Automatic |
Volts (V): | 115 |
Amperage: | 2.0 |
Shaft Dimensions (in): | 5/16 x 3.2 |
Mounting Type: | Stud |
Has 360 Photos: | Yes |
Replaces Old Numbers: 0Y-DLN2-JET0, 1043336, 2868-513-101, 2868-513-105, 2868-811-010, 5001L, 5008S, 5008SS, 5034L, 5KSM59JSK143, 7163-2113, 7163-3181, 7163-7217, 7163-8722, 777980002408, 81909, 8214117230, 8214117280, 82194, 85089R, AA2R6015, B01MR6Q9TA, B01N38FWIW, B07SZHDY7R, D1101, D1120, D1124, E1052, E1055, E1057, E1058, JA2R262N, JA2S078, JA2Y016N, KR1043336, LSA, LSG, LV1500, LV2000, LVG1500, LVG2000, M1009A, M5-S1124, R358, S1124, SS358
