UE-591 : A.O. Smith 1/10HP Fancoil/Air Conditioning Motor 5.0" Dia. 1050 RPM, 115V
A.O. Smith 591 Fancoil & Double Blower Motor.
Application Air Conditioning Fancoils & Double Blowers using these specifications.
Product Downloads
Installation Instructions
| Product Specifications | |
|---|---|
| Mounting Type: | Resilient, Rings Included |
| HP: | 1⁄10, 1⁄20, 1⁄30 |
| Body Diameter (Inches): | 5.0 |
| Volts: | 115 |
| Frequency: | 60/50Hz |
| Amps: | 3.0, 1.9, 1.4 |
| RPM: | 1050 |
| Speeds: | 3 |
| Rotation: Opposite Shaft End: | |
| Bearing: | Sleeve |
| Enclosure: | Open |
| Rotation Double Shaft: Lead End: | CW |
| Shaft: Diameter x Length (Inches): | 1/2 x 10-11/16 x 1/2 x 10-11/16 |
| Motor Type: | Shaded Pole |
| Body Length (Inches): | 3-1/2 |
| Thermal Protection: | Automatic |
| Ambient Temperature (Celsius): | 40 |
| Mounting: | Resilient, Rings Included |
| Frame: | 42 |
| Volts (V): | 115 |
| Amperage: | 3.0, 1.9, 1.4 |
| Shaft Dimensions (in): | 1/2 x 10-11/16 x 1/2 x 10-11/16 |
| Ambient Temperature (C): | 40 |
| Clearance: | Yes |
| Has 360 Photos: | Yes |
Replaces Old Numbers: 29122005915, 40389, 591, 591SS, 7151-0058, 7151-2200, 7151-2299, D256, R3A1A2-H82, S2904, UE591, UR3A1A-A39
