UH-9034 : Alltemp 1/6 HP Unit Heater Direct Drive Motor 5.5" Dia. 1075 RPM, 115V
Compare at: $ 300.76
You Save: $ 27.34
SHIPS: IMMEDIATELY
Unit Heater Motor UH-9034 1/6 HP. 5.5" Diameter.
Application Unit Heaters and Other Shaft-mounted Fan and Blower Equipment in Dusty, Dirty, Non-combustible Environments.
Optional Mounting Base UH-UHK. For UH- Series Includes Base, Brackets & Resilient Rings.
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Body Diameter (Inches): | 5-5/8 |
| Frame: | 48Y |
| HP: | 1/6 |
| Volts (V): | 115 |
| Frequency: | 60Hz |
| Amperage: | 2.8 |
| Phase: | 1 |
| RPM: | 1075 |
| Speeds: | 1 |
| Rotation: | Reversible |
| Bearing: | Sleeve |
| Enclosure: | Totally Enclosed |
| Shaft Dimensions (in): | 1/2 x 2.5 |
| Motor Type: | Permanent Split Capacitor |
| Body Length (Inches): | 6.0 |
| Capacitor: | 5MFD 370V |
| Capacitor Included: | Y |
| Thermal Protection: | Automatic |
| Ambient Temperature (C): | 40° |
| Insulation Class: | B |
| Service Factor: | 1 |
| Mounting Type: | Through Bolts & Resilient Rings |
| Bolt Circle Diameter (Inches): | 3-5/8, 3-5/8, 45/8, 2-5/16 |
| Wiring: | Leads |
| Has 360 Photos: | Yes |
| Clearance: | Yes |
Replaces Old Numbers: 177AOS, 3206, 34W65, 3M899, 70066, 7126-0316, 7126-0317, 7126-0319, 7126-0351, 777980040769, 9034, B077Q3W8BF, D733, D834, F-161, F42E17C04, F48SF6V3, K5345, K818, K9034, UH1016, US1016, US1016NB, X302, X306
