O1-R455 : MOTOR HRV DIRECT DRIVE 1/20HP 1550 RPM 3 SPEED GENERAL REPLACEMENT
Rotom R455 HRV Motor General Replacement.
Use with HRV ( Heat Recovery Ventilation ) Units.
Will Replace HRV motors requiring these specifications.
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Body Diameter (Inches): | 3.3 |
| Frame: | 3.3 |
| HP: | 1/20 |
| Volts: | 115 |
| Amps: | 2.0 |
| RPM: | 1550 |
| Speeds: | 3 |
| Rotation Double Shaft: Lead End: | CW |
| Bearing: | Sleeve |
| Enclosure: | Open |
| Shaft: Diameter x Length (Inches): | 5/16 x 4.62 & 5/16 x 3.88 |
| Motor Type: | Shaded Pole |
| Body Length (Inches): | 3.25 |
| Mounting: | Stud or Strap |
| Volts (V): | 115 |
| Amperage: | 2.0 |
| Shaft Dimensions (in): | 5/16 x 4.62 & 5/16 x 3.88 |
| Mounting Type: | Stud or Strap |
| Clearance: | Yes |
Replaces Old Numbers: 01-R455, 2868-505-089, 2868-507-036, 2868-513-085, 7121-3273, 7121-3371, 7121-4713, 7121-4892, 80705, 82364, D209, D364, F2478, F-3440, R455
