DP-3P40A120 : Definite Purpose Magnetic Contactor, 3 Pole 40A 120V, Box Lug Type
Compare at: $ 101.77
You Save: $ 9.25
SHIPS: IMMEDIATELY
Alltemp DP-3P40A120 Definite Purpose Magnetic Contactor. 40 Amp, 120 Vac, 3 Poles.
Furnas #42CF35AF
Contactors are designed to establish or interrupt a power circuit. Definite purpose contactors unlike general purpose contactors are non-rebuildable electronic controls designed for specific application with clearly defined operating conditions.
Totally enclosed
Compact size
Quieter than traditional designs
Far more efficient operation
Features lug, spade terminals and protective covers
Quick connect and screw terminals on coil.
Universal galvanized mounting plates
Snap on auxiliary contacts available
ARI 780/790 standards
cURus approved
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Poles: | 3 |
| Full Loaded Amps: | 40 |
| Coil Voltage 50/60: | 120 |
| Locked Rotor Amps (240V): | 240 |
| Resistive Amps: | 50 |
| Height (in): | 2.99 |
| Width (in): | 2.37 |
| Depth (in): | 3.75 |
| Locked Rotor Amps (480V): | 200 |
| Locked Rotor Amps (600V): | 160 |
| Termination: | Box Lug |
| Has 360 Photos: | Yes |
Replaces Old Numbers: 037H2156-21, 777980044705, HC-340120
